Products   >   Communications Modules   >   NVIDIA Solutions   >   JETBOX-nano™ low-cost Enclosure Solution for NVIDIA Jetson Nano Development Kit

JETBOX-nano™ low-cost Enclosure Solution for NVIDIA Jetson Nano Development Kit

Rugged, durable enclosure for NVIDIA Jetson Nano development kit

NVIDIA

Ever since its introduction in March of 2019, the NVIDIA Jetson Nano computer-on-module has been capturing the hearts and minds of AI systems builders everywhere. JETBOX-nano™ is a low-cost enclosure for the Jetson Nano development kit. The all-steel enclosure provides a rugged, durable enclosure solution for the Jetson Nano that measures a compact 125mm x 95mm x 34mm (approx. 4.9 x 3.7 x 1.3 inches). The combination of the Jetson Nano development kit with the JETBOX-nano means users can deploy a professional quality NVIDIA Jetson system with almost 500 gigaFlops performance.

JETBOX-nano front (model JETBOX-NANO-KIT-02) on the left and the back shown on the right.

The NVIDIA Jetson Nano Development Kit provides plenty of I/O for makers, learners, and developers.

Jetson Nano Developer Kit with I/O callouts

The JETBOX-Nano measures a compact 125mm x 95mm x 34mm (approx. 4.9 x 3.7 x 1.3 inches). Its 2-part design makes assembly quick and easy. In addition to the standard front-facing I/O connectors, the enclosure provides access to the serial port and camera flex cable port on the Nano development kit’s left side and the GPIO port on its right. A programming button on the rear enables easy software updates, and a DIN rail mount makes installation in end equipment easy.

JETBOX-nano comes as an easy to construct kit that includes everything needed to construct the durable, quality enclosure designed to house the NVIDIA Jetson Nano development kit:

  • Top and bottom enclosure pieces with assembly hardware
  • Rear programming button
  • DIN rail mounting bracket
  • Optional GPIO cable (-02 model)
  • Easy-to-follow instructions for building JETBOX-nano

The JETBOX-nano enclosure kit is available in two configurations: The basic model and a GPIO-enabled model that includes a GPIO feature connector on the right side. The Nano development kit is purchased separately and is readily available from online vendors. Contact Diamond for options regarding availability of a fully-assembled, ready-to-run system including the Nano development kit pre-installed.

top
How to buy the NVIDIA Jetson Nano development kit

The JETBOX-nano kit comes with everything needed to assemble the kit (JETBOX-NANO-KIT-02 shown)

The development kit is sold online by many vendors. Here are just a few to choose from: Amazon.com, Sparkfun, Newegg, Seed, Arrow, or from NVIDIA's Jetson Store

Looking for more information about the development kit and how product developers are using it? NVIDIA's Autonomous Machines section on their website provides plenty of information to fuel your ideas. Getting started with the developer kit (NVIDIA developer site).

Links to get you started via NVIDIA's online developer resources:

top
Get an online quote


JETBOX-nano™ low-cost Enclosure Solution for NVIDIA Jetson Nano Development Kit
available models:
JETBOX-NANO-KIT-01
JETBOX-nano enclosure, with GPIO feature
JETBOX-NANO-KIT-02
JETBOX-nano enclosure, No GPIO feature
Please login or signup for an online quote request.



FEATURES
Designed for Jetson Nano development kit
Sturdy all-steel construction
Quick assembly
Tabletop and DIN rail mounting
Access to GPIO features with optional cable
Dimensions: 125mm x 95mm x 34mm (approx. 4.9 x 3.7 x 1.3 inches).
Weight (fully assembled with Jetson DK): xxx
