Small Form Factor Digital I/O Modules

Diamond's Digital I/O module family includes a wide range of rugged, wide-temperature PC/104, PC/104-Plus, PCIe MiniCard, and FeaturePak modules featuring programmable bi-directional digital I/O, counter/timers, optoisolated inputs, and relay outputs.

Click below for detailed information on our digital I/O modules:

PC/104

GPIO-MM-XT

PC/104 module with 48 line digital I/O plus 10 counter/timers, reconfigurable

Onyx-MM

PC/104 module with 48-line digital I/O, 3 counter/timers, and 3 interrupts; supports extended temperature operation

Onyx-MM-DIO

Low-cost PC/104 module with 48-line digital I/O; supports extended temperature operation

Opal-MM-1616

Opal-MM 16 Optoisolated Input & 16 Relay Output PC/104 Module

Pearl-MM

PC/104 module with 16 SPDT relay outputs

IR104-PBF

PC/104 module with 20 optoisolated inputs and 20 5A rated relay outputs

PCIe MiniCard

DS-MPE-GPIO

PCIe MiniCard I/O Expansion Module with Digital I/O & FPGA

> > See our Digital I/O & Counter/Timer Modules feature comparison chart < <

Other I/O Expansion Modules

Diamond's product line also includes the following I/O expansion module families:

Analog I/O Modules -- A/D, D/A, DIO, and counter/timers
Communications Modules -- serial interfaces, Ethernet, CAN bus, GPS, and digital I/O

Back to top
	Comparison of Digital I/O and Counter/Timer I/O Modules

Digital I/O							Counter/Timers			Miscellaneous
Product	Form Factor	# I/O	Buf	Prog	Optos	Relays	# Ctrs	Res	Max	IRQ	XT
OMM-XT	PC/104	48 I/O		Yes			3	16	10MHz	3	Yes
OMM-DIO-XT	PC/104	48 I/O		Yes							Yes
PMM-P	PC/104					16					Yes
OPMM-1616-XT	PC/104				16	16					Yes
IR104-PBF	PC/104				20	20
GPIO-MM	PC/104	48 I/O		Yes			10	16	40MHz		Yes
GPIO-MM-12	PC/104	48 I/O		Yes			10	16	40MHz		Yes
GPIO-MM-21	PC/104	48 I/O		Yes			10	16	40MHz		Yes
P104-GPIO96	PC/104-Plus	96 I/O	Yes	Yes			8	32			Yes
DS-MPE-GPIO	PCIe MiniCard	36 I/O		Yes			4	32			Yes
FP-GPIO96	FeaturePak	96 I/O	Yes	Yes			8	32			Yes

Legend

I/O	Programmable direction

Headings

Buf	Buffered outputs
Prog	Prog. direction
Res	Resolution
Max	Max clock input rate
IRQ	Interrupt outputs
XT	-40 to +85 degrees C
